— Product Catalogue
Precision
engineered.
Built to last.
A complete range of hydraulic hoses, fittings, ferrules and accessories — assembled and tested in-house.
01 / Hydraulic Hoses
SAE & EN Series
All hoses conform to their respective SAE J517 or EN standards. Custom lengths & fittings available.
Standard
Description
Working Pressure
Temp Range
SAE 100R1
One-wire braid, medium-pressure hydraulic
88–225 bar
-40 to +100°C
SAE 100R2
Two-wire braid, high-pressure hydraulic
88–415 bar
-40 to +100°C
SAE 100R7
Thermoplastic single-wire, hydraulic
70–350 bar
-40 to +100°C
SAE 100R9
Four-spiral wire, extra-high pressure
280–420 bar
-40 to +100°C
SAE 100R12
Four-spiral wire, high pressure
280 bar
-40 to +121°C
SAE 100R13
Multi-spiral wire, ultra-high pressure
345 bar
-40 to +121°C
SAE 100R15
Four/six spiral wire, constant working pressure
420 bar
-40 to +121°C
EN 856 4SP
Four-spiral wire, extreme abrasion
350–450 bar
-40 to +100°C
EN 856 4SH
Heavy-duty four-spiral wire
420 bar
-40 to +100°C
02 / Fittings & Adaptors
Every thread. Every seal.
Precision-forged carbon steel and stainless fittings in every standard used in Indian and global hydraulics. Zinc-nickel plated for corrosion resistance.
01
BSP · British Standard Parallel
02
BSPT · British Standard Taper
03
JIC 37° Flare
04
ORFS · O-Ring Face Seal
05
SAE 45° Flare
06
SAE Flange Code 61 / 62
07
Metric DIN 24° Cone
08
NPT · National Pipe Taper
03 / Accessories & Consumables
Around the assembly.
01 / 06
Ferrules
One-piece and skive-type ferrules for R1/R2/R9/R12 assemblies.
02 / 06
PTFE Hoses
Chemical-resistant, high-temperature applications.
03 / 06
Suction & Return
Low-pressure large-bore hoses for tank returns.
04 / 06
Spiral Guards
Polyethylene spiral wrap to protect hose OD from abrasion.
05 / 06
Fire Sleeves
Silicone-coated firesleeve for engine bays and hot zones.
06 / 06
Custom Assemblies
Made-to-print assemblies with your part number and drawing.
